AC Hydraulic GDT150 telescopic pneumatic hydraulic pit lift

AC Hydraulic GDT150 telescopic pneumatic hydraulic pit lift

SKU: BD13370
SKU:: GDT150

7,545.00 €

Prices shown include tax

Send Message

Description

AC Hydraulic GDT150 telescopic pneumatic hydraulic pit lift

AC-Hydraulic, Denmark; Warranty: 3 years for hydraulics and 10 years for body parts

Telescopic pneumatic-hydraulic single cylinder pit lift truck

Description:

- The downgraded design doubles the performance compared to standard pit lifts

- Low construction height with long stroke

- Fast and accurate pneumatic-hydraulic axle hoist with high-speed cylinder

- Simple modern design with control panel and ergonomic working height

- Can be adapted for use with all trucks due to its adjustable body

- The height of the casing is adjusted and adjusted according to the customer's requirements

- Sliding cylinder locking at 800 kg

- Emergency release and overload valve for optimum safety

- Manufacturer: Denmark

- Warranty: 3 years

Technical parameters:

- Lifting capacity: 15 tonnes

- Stroke of piston: 1280 mm

- Minimum height: 900 mm

- Maximum height: 2180 mm

- Lift length: 725 - 1410 mm

- Lift width: 735 mm

- Required compressed air pressure: 8 - 12 bar

- Required compressed air flow: 350 L / min

- Weight: 250 kg
