Air dehumidifier Ultrapac ALD 0150st

Air dehumidifier Ultrapac ALD 0150st

TLD features:

• Complete compressed air or nitrogen treatment kit consisting of an adsorption dryer with integrated oil and dust filter and automatic condensate drain.
• Medium: compressed air / nitrogen
• –40 ° C at 100% load, –70 ° C at 70% flow at 35 ° C inlet temperature.
• Operating pressure: min. 4 bars (g), maximum 16 bars (g)
• Average temperature: min. 5 ° C, not more than 50 ° C
• Ambient temperature: min. 4 ° C, not more than 50 ° C
• Compressed air consumption: 17% on average, depending on the inlet value
• Power supply: 230 V / 50-60 Hz AC; 110 V / 50-60 Hz constant 24 V DC; 24 V AC on request

Technical data:

• Capacity: 150 m3 / h
• Air consumption: 23 m3 / h
• Connection: 1
• Width / depth / height: 77x68x198 cm
• Additional information: the set includes a pre-filter, an underwater filter and an automatic channel drain
• Temperature -40 ° C at 100% load, -70 ° C at 70% load
• Product code: OZ6053
