Air hydraulic press for truck workshops and industry AC hydraulic P40LH

Air hydraulic press for truck workshops and industry AC hydraulic P40LH

The air hydraulic press work is fully operated via the foot control, and both hands remain free to handle the item

• Traversing ram
• With 300 mm stroke for dealing with demanding jobs
• Built-in pressure gauge at convenient eye level
• Wide, welded frame and press table ensuring high flexibility
• Winch operated press table
• Built-in safety overload valve
• Removable ram end cap for mounting of various piston heads
• Supplied with 2 vee blocks

Technical data:

• Capacity: 40 t
• Stroke: 300 mm
• Height: 1900 mm
• Width: 1050 mm
• Width between legs: 850 mm
• Depth between legs: 215 mm
• Clearance: 70 - 770 mm
• Weight: 425 kg
• Press speed at 9 bar is 10mm/sec
