Automatic powder coating line COLO

Automatic powder coating line COLO

• The multicolor powder booth system developed with the cyclone device increases the color change efficiency. This system is also built using automatic spray equipment and an intelligent powder supply center.
• Cyclone type automatic powder booth features
• The mono cyclone achieves recycling efficiencies of up to 98%, thus saving powder. quick cleaning takes about 15 minutes.
• The secondary recovery stage is combined with a group of high-precision filters that efficiently collect ultra-fine powder, releasing only particle-free air outside.
• The air cleaning system continuously transfers the spray powder from the cab floor, quickly recycling it back to the powder supply container.
• The cab material can be made of antistatic engineering plastic, which reduces powder waste.
• The central control cabinet connects all the gun controls, so it is not possible to set parameters in just one main unit to control the entire system.
• The COLO-191S powder coating machine uses the latest DVC technology, which allows flexible and accurate setting of all parameters, providing impeccable quality.
• 100 sq. M. spray gun quickly charges powder, provides high transfer efficiency, increases powder utilization.
• Powder coating re - apparatus
• Linear rail guide mechanism, belt travel, adjustable frequency motor, PLC controlled, for smoother, more stable and more precise movement.
• Moving speed and stroke can be easily set on the touch screen with 20 stored programs.
• Allows you to place the powder box directly on the funnel, which is flexible for color changes.
• Automatic cleaning of sprayers, powder hoses, nozzles by changing color reduces labor and increases efficiency.
• Ultrasonic sieving of fresh powder and regeneration powder, dissolution and loosening of powder aggregates to ensure even flow of powder.
• A closed powder hopper with a sister will detect the powder position and an alarm when powder is missing.
• A convenient PLC touch screen panel facilitates the process.
