Car body tensioning stand Winner M-30

Car body tensioning stand Winner M-30

Warranty period 12 months.

Description:

• The set includes MB / BMW printers / kit;

• Double tilt system with 2 columns
• The platform is made of steel plates
• Technical specifications:
• Platform length: 5700 mm
• Platform width: 2100 mm
• Platform height: 300-1050 mm
• Hydraulic pressure: 70 MPa (10000psi)
• Voltage: 95 CN
• Working range: 3600 °
• Pneumatic pressure range: 0.8 MPa
• Max. Lifting weight: 3500 kg
• Total weight: 2600kg

Functions:

• The vertical lifting platform can be raised to a height of 300 ~ 1050 mm, taking care of the mechanics of different heights.
• The hydraulic double draw tower can work flexibly at an angle of 0 - 360 degrees.
• The hydraulic system is powerful, reliable and durable.
• The high-precision super work platform is the best place for universal single-device applications.
• The general-purpose mechanical measuring system can be easily used to measure a car in three dimensions.
• A car data guide is provided which always updates the data.
• A complete set of flat work tensioning and pulling tools is provided, taking into account any type of conversion
