COLO LINE automatic powder coating line 1

COLO LINE automatic powder coating line 1

• Transmission system: closed-loop conveyor for powder coating.
• Automatic powder booth: with cyclone or filter recovery stage made of plastic
• Automatic spray gun and piston: consistently and uniformly powder coated
• Powder Supply Center: Maximize powder supply, cleaning, and control
• Curing tunnel: uniform heating temperature ensures quality results
• The compact automatic powder coating line includes a powder spray booth with regeneration system, automatic coating guns and plunger, powder supply equipment, curing tunnel and conveyor system.
• Cyclone type automatic powder booth features
• The mono cyclone achieves high processing speeds and extremely fast cleaning when the color changes in about 15 minutes.
• The secondary recovery stage is combined with a group of high-precision filters that efficiently collect ultra-fine powder, so only air without particles is released outside.
• The air cleaning system continuously transfers the spray powder from the cab floor, quickly recycling it back to the powder supply container.
• The central control cabinet connects all the gun controls for integrated control, allowing parameters to be set in just one main unit to control the entire system.
• The COLO-191S powder coating machine uses the latest DVC technology, which allows flexible and accurate setting of all parameters, providing a flawless and consistent quality finish.
• The 100 sqm spray gun powerfully charges powder, provides high transfer efficiency, increases powder utilization.
• Proven reliable system based on COLO 10 years of technology.
• Powder coating re - apparatus
• Linear rail guide mechanism, slide up and down belt, adjustable frequency motor controlled by PLC, providing smoother, more stable and more precise movement.
• Motion speed and shock can be easily set on the touch screen with 20 stored applications.
• The slim column design saves space in the arms.
• Inconvenient uniformity and consistency of quality, reduce powder consumption.
• Continuously, evenly, quantitatively feed the powder into the sprayer.
• Automatic cleaning of sprayers, powder hoses, nozzles by changing color reduces labor and increases efficiency.
• The sewing section ensures that only high-quality powder is recycled, mixing fresh and regenerated powder increases the use of powder.
• 100 liter powder hopper.
• The sener will detect the position of the powder and signal when there is a lack of powder.
• A user-friendly touch screen panel simplifies the process.
• Powder Coating Curing Tunnel
• The vulcanization tunnel is made of 100 mm stone wool board with a galvanized steel wall, is characterized by durability and heat resistance.
• Raise quickly and evenly to the required temperature up to 250 ° C, increase production efficiency
• With a fan that ensures an even temperature.
• The heating source can be electric, gas or diesel, the latter being more recommended to cover economic costs.
