Electro-hydraulic self-propelled loader 1000 kg NH Handling SKS1229

Electro-hydraulic self-propelled loader 1000 kg NH Handling SKS1229

Manufacturer: NH Handling (Denmark) Warranty: 3 years

• Can be operated by handles
• All steering and control elements are ergonomically arranged in the steering handle
• PIN code panel
• Pulse control from fast to slow
• When the steering wheel is released, the truck brakes automatically
• Do not unscrew when the truck starts to lift
• Built-in charger: 1 x 230 V / 24 V - 12 Amp
• Can be mounted with a meter limiter

Technical data:

• Lifting capacity: 1200 kg
• Lifting function: electric hydraulic
• Drive motor: Hangzhou
• Battery: 2x12 v / 85 Ah
• Lifting height: 2900 mm
• Overall height: 3337 mm
• Fork lifting height: 1930 mm
• Unladen speed 4.6 / 4.2 km
• lifting speed u / m load: 19/12 mm / s
• Maximum load increase u / m: 10 / 5˚
• Fork width: 570 mm
• Fork wheels Ø: 84 x 93 mm
• Steering / drive wheels Ø: 210 x 70 mm
• Support wheels - adjustable Ø: 100 x 60 mm
• Weight: 594 kg
