Fuel storage capacity MOBILE

Homologated fuel filling tanks MOBILI, they are made of the highest quality structural steel EN10025 S235JR sheets. These tanks are designed to store diesel, with capacities ranging from 500 to 9,000 liters as standard models, and can have an additional protective bottom to prevent fuel from entering the environment and is able to withstand up to 110% of the full tank capacity. Its exterior is coated with acrylic bi-component spray paint. The protective roof is made of stainless steel sheets. It can also be equipped with fuel delivery equipment in a box, square or with a stand, the capacity of which is 40 - 90 l / min. These tanks have 7767/4113, 269 homologations granted by a special commission appointed by the Italian Ministry. Also, the option is to make the product from stainless steel Aisi 304 or 316. Can be adapted for use with gasoline.


Bakas

The tank is in a horizontal position and raised from the ground by special support brackets, a lifting loop is installed at the top of the tank (it can only be used when the tank is empty), has an earth point.


Running tray, sole

Sturdy support housing attached to the tank tank. It is equipped with special places, if a roof and a drainage screw ¾ ”diameter will be installed at the sole. This sole is designed to withstand about 110% of the tank's capacity.


Roofs

It is mounted on a solid, galvanized frame.


Main hatch

Diameter: 420 mm with sealing gasket. Equipped with a 3-diameter quick coupling, a coupling made of brass, a locking pin, an overflow safety valve, homologated, allows the tank to be filled to 90% of the full tank capacity. Mechanical level gauge with protective structure. Air vent valve, cone-shaped.

Drain valve: they are installed in a convenient position to prevent various impurities from entering the exhaust fuel. A ball valve and a non-return valve are installed. Drain plug for any periodic maintenance.

Information table

Each refueling tank has an individual metal identification plate with a serial number and homoligation information.


Tank tanks, generators and heating equipment

2 connectors, 1 ”for power supply and return. Mechanical level gauge, lockable 3 ”air vent valves and flame extinguishing valves. 90% filling valve to protect against overfilling, with fitted drain / soleplate, roof can be ordered as an option.
