Lamp adjustment stand PH2066 with light flow adjustment

Lamp adjustment stand PH2066 with light flow adjustment

Manufacturer WT-Engineering (Italy)

The PH2066 headlight adjustment stand is an extremely versatile and easy-to-use device. The stand can be purchased in different versions to meet everyone's expectations, and all stands have a moving column.

Available versions:

PH2066/LFM - Fresnel Lens, Digital Luxmeter, Laser Straightness, Mobile Display

PH2066/L2FM - Fresnel Lens, Digital Luxmeter, Laser, Dual Straightness, Mobile Display

PH2066/LMV - Glass Lens, Digital Luxmeter, Laser Straightness, Mobile Display

PH2066/L2MV - Glass Lens, Digital Luxmeter, Laser, Dual Straightness, Mobile Display

For an additional cost, 4 meter long rails with screws and necessary pins can be ordered for these stands for EUR 180.00 including VAT

Technical characteristics:

Measuring height: 250 - 1500 mm

Lens diameter: 230 mm

Brightness measurement: 0 - 240 Lux, 25 mt.

Dimensions: 600 x 700 x 1700 mm

Weight: 38 kg

Prices with VAT:

PH2066/LFM = €655.00 including VAT

PH2066/L2FM = €680.00 including VAT

PH2066/LMV = EUR 720.00 including VAT

PH2066/L2MV = EUR 730.00 including VAT
