Large powder coating furnace COLO 5219

Large powder coating furnace COLO 5219

• It heats faster by using gas or diesel as fuel, and is more economical with less energy and maintenance costs.
• The crown is made of durable and high-quality components that never compromise on quality and performance.
• Using a PLC system to control all heating processes, accurate and convenient.
• The Riello burner completely burns fuel (gas or diesel) and quickly reaches the required temperature.
• Circulating fans cause a uniform temperature throughout the chamber, which results in quality curing.
• The 100 mm thick stone wool board always keeps the chamber with minimal heat loss.
• Powder coating furnaces of the required size, such as 6 m, 7 m, 8 m or more, can be adapted.

Technical data:

• Power supply: LPG / gas / diesel
• Voltage / frequency: 380 V / 220 V (50-60 Hz)
• Warm-up time: 15-30 min. (180 ° C)
• Temperature stability: <± 3.0-6 ° C
• Max. Temperature 250 ° C
• Transport system
• Two wheelchairs
• Burner: 10,0000 cal
• Circulation / air flow vertical, variable through holes in the walls
• Ventilation efficiency: 8288-16576 m3 / h
• Engine power: 7.5 kW
• Dimensions of working size: width 1800 mm, height 1800 mm, depth 5000 mm
• General dimensions: width 2100 mm, height 2200 mm, depth 5200 mm
