Non - contact tunnel cleaner Pulse HP

Non - contact tunnel cleaner Pulse HP

• Stainless steel side cover plates
• Hot-dip galvanized frame, polyurethane powder paint
• Stainless steel screws
• Belt safety control for horizontal elements
• Variable speed control and protection system for the upper brush and the drying lift
• Stainless steel contour dryer: (2 x 3 kW)
• Two side dryers (2 x 4 kW)
• Five-position contouring and tilting of the highest pressure device with switching nozzle
• High side pressure with vertical turning nozzle
• Direct speed motor variable drive
• Chemical wax pump
• Up to 6 chemicals can be combined
• Standard power supply: 380/415 V - 50 Hz

Technical data:

• Max. washing height: 2,300 mm
• Max. washing width: 2,300 mm
• Width between columns: 2,450 mm
• Maximum height: 3.015 mm
• Maximum width: 3,570 mm
• Length of pallets: 9 m
• Distance between rails: 2850 - 3000 mm
