Pneumatic-hydraulic pit-mounted jack AC Hydraulic GGD150S

Pneumatic-hydraulic pit-mounted jack AC Hydraulic GGD150S

SKU: BD13420
SKU:: GGD150S

7,355.00 €

Prices shown include tax

Send Message

Description

Pneumatic-hydraulic pit-mounted jack AC Hydraulic GGD150S

AC-Hydraulic, Denmark; Warranty: 3 years for hydraulics and 10 years for body parts

Pneumatic-hydraulic pit-mounted hoist with sliding telescopic cylinder

Description:

- The sliding cylinder ensures wide reach under the car and allows the mechanic to move freely in the pit

- Extremely well suited for gearbox assembly and assembly

- Integrated foot pump for easy and precise adjustment

- Fast and accurate pneumatic-hydraulic axle hoist with high-speed cylinder

- Wheel support with integrated springs prevents unwanted movement when lifting over 800 kg

- Base housing castors with integrated bearings for optimum maneuverability

- Feet-controlled, leaving hands free

- Emergency release with overload valve for optimum safety

- Manufacturer: Denmark

- Warranty: 3 years

Specification:

- Lifting capacity: 15/15 tonnes

- Stroke of piston: 1285 mm

- Minimum height: 905 mm

- Maximum height: 2190 mm

- Lift length: equal to pit width

- Lift width: 940 mm

- Cylinder diameter: 60 mm

- Required compressed air pressure: 8.5 - 12 bar

- Required compressed air flow: 350 L / min

- Weight: 250 kg

- 100 x 100 x 10 mm rails should be installed at the bottom edges of the pit
