Pneumohydraulic pit lift AC Hydraulic GGD150F

Pneumohydraulic pit lift AC Hydraulic GGD150F

SKU: BD13400
SKU:: GGD150F

6,760.00 €

Prices shown include tax

Send Message

Description

Pneumohydraulic pit lift AC Hydraulic GGD150F

AC-Hydraulic, Denmark; Warranty: 3 years for hydraulics and 10 years for body parts

Pneumatic-hydraulic pit floor hoist with telescopic cylinder

Description:

- Versatile hoist for use in both pits and under car lifts

- Suitable for all normal lifting operations

- Extremely well suited for gearbox assembly and assembly

- Integrated foot pump for easy and precise adjustment

- Fast and accurate pneumatic-hydraulic axle hoist with high-speed cylinder

- Wheel support with integrated springs prevents unwanted movement when lifting over 800 kg

- Equipped with emergency release and overload valve for optimum safety

- Manufacturer: Denmark

- Warranty: 3 years

Specification:

- Lifting capacity: 15/15 tonnes

- Stroke of piston: 1285 mm

- Minimum height: 920 mm

- Maximum height: 2205 mm

- Lift length: 845 mm

- Lift width: 1005 mm

- Cylinder diameter: 60 mm

- Required compressed air pressure: 8.5 - 12 bar

- Required compressed air flow: 350 L / min

- Weight: 220 kg
