Tire changer machine ATH M52 (Germany)
Tire changer machine ATH M52 (Germany)
Tire changer machine ATH M52 (Germany)
Tire changer machine ATH M52 (Germany)

Tire changer machine ATH M52 (Germany)

  • SKU: BD63930
4,235.00 €

Prices shown include tax

Send Message

Description

Tire changer machine ATH M52 (Germany)

Country of origin: ATH-Heinl (Germany); Warranty 36 months

Description:
  • Wheel mounting machines with pneumatic mounting column;
  • The machine body is coated with high quality powder coating;
  • External gripper up to 22 '', additionally adjustable up to -2;
  • Pneumatic clamping of the mounting head with automatically adjustable vertical / horizontal distance control;
  • Squeezing press with jam protection;
  • Wheel alignment with four gripper system, 2 double-acting clamping cylinders;
  • Pedal block with aluminum valves and ergonomic pedal layout.
Technical data:
  • Internal clamping range 14 - 26 "
  • External clamping limits 12 - 22 "
  • Rim width 4 - 13 "
  • The maximum wheel diameter is 1050 mm
  • The stroke of the compression press is 85 - 330 mm
  • Pressing force 2800 kg
  • Mounting table rotation speed 6 rpm
  • Operating pressure 10 bar
  • Power 0.75 kW
  • Power supply 400 V AC / 50 Hz
  • Sound level 70 dB (A)
  • Weight 240 kg
Auxiliary pneumatic mounting accessory ATH A34
  • This is especially convenient for mounting large diameter wheels, low profile tires and run-flat tires with reinforced edges.
  • It is possible to order an auxiliary mounting handle: left or right (as convenient).
  • Weight: 90/110 kg
  • Compressed air connection - Minimum 10 bar
