Tire changer Redats M-230

Tire changer Redats M-230

Manufacturer: Redats. Country: Poland. Warranty 2 years

Automatic tire fitting machines, guaranteed working comfort - a lot of work is done for you. With the help of the pedal you will move the column back and forth, so no physical force is required, as it is done automatically. The most important technical parameters of the following assembly machines: inner rim diameter: 12'-24 "; outer diameter: 10-22"; maximum rim diameter: 1000 mm; maximum rim width: 355 mm.

Technical data:

• Type: automatic
• Power supply: 3 phases, 400V
• Inner Rim Mounting: 12-24 "
• Outer rim mounting: 10-22 "
• Max. wheel diameter: 1000 mm
• Max. wheel width: 355 mm
• Tire deflated power: 3200 kg
• Engine: 0.75 kW
• Working pressure: 8 - 10 bar
• Noise level: <70 dB
• Max. torque: 1200 Nm
• Table rotation speed: 7 rpm
• Weight: 229 kg
• Dimensions: 189 x 130 x 950 cm

Equipment:

• Tire fitting machines
• Plastic guards
• Pressure regulator with oil filter
• Inflatable spray gun with manometer
• Tire mounting lever 50cm
• Bucket of grease
• Plastic gripper guards (4 pcs)
