Ultrasonic bath GUYSON CRD450 36L

Ultrasonic bath GUYSON CRD450 36L

The CRD450 is a manually operated precision ultrasonic cleaning system that provides ultrasonic cleaning with heating, immersion rinsing, a manual spray for a second rinse and hot air circulation drying to a maximum temperature of 100 ° C - all in one integrated unit.

The CRD is a 3-level ultrasonic cleaning system suitable for applications such as: PCB cleaning, metal finish cleaning, maintenance cleaning and removal of oils, sawdust, polishing compounds and carbon deposits. Standard CRD converters operate at 38 kHz (± 10%) and are equipped with two internal M300 (300 W) Kerry generators; however, optional external generator control allows dual frequency control (40/80 kHz ± 10%) and variable power control.

Ultrasonic transducers connected to the base of the tank ensure high efficiency and reliability as well as even distribution of ultrasonic energy. The frequency is adjusted according to a separate tank / converter combination and then optimized under normal conditions of use by performing frequency cleaning and fully automatic tuning.

Features:

The CRD system is for manual use only

Digital panel for accurate control and display of time and solution temperature

Generator control with double frequency

Standard CRD systems operate at 38 kHz (± 10%)

Optional: additional filter in the cleaning tank, heating to the rinsing liquid and water spray

Technical data:

Internal dimensions: 450 x 325 x 250 mm

External dimensions: 1500 x 800 x 975 mm

Capacity: 36.5 l
