VAG adaptations and component protection package

VAG adaptations and component protection package

Manufacturer: ABRITES, Bulgaria

Component adaptation package VN002

It is a very powerful package of special functions used for customizing various parts and synchronizing modules in cars. It works with both data and modules related to immobilizers. The package supports work with the following car manufacturers: Audi / Volkswagen / Seat / Skoda / Bentley / Lomborghini or even some Porsche models.

Modules related to immobilizer data:

Using this VN002 package, you will be able to scan, update the IMMO data (PIN, CS, MAC), which will allow you to adapt the used parts, components to the desired car. Supported modules:

• Engine control module (ECU). (EDC15 / EDC16 / EDC17 / MED17 / ME7 / MED9.x / Simos PPD / Simos PCR2.1 / Magneti marelli 4HV and 7HV and others.
• Transmission Control Module (TCU). S-Tronic (DL501), DSG (DQ200 and DQ250) and CVT.

Read component protection bits from ZF8HP

• Immobilizer
• Electronic steering locks (ESL)
• Dashboards (Detailed information can be found in the ABRITES user manual)

Component protection

There are other modules that do not require IMMO data customization, but require component protection synchronization. Without this synchronization, the modules operate with limited functions (e.g. intermittent radio sound). These modules can be grouped as follows:

• 1st generation component protection: Audi A8 2003 – 2010; Audi A6 2004 - 2008; MMI, CD player, ILM and other modules
• 2nd generation component protection: Audi A6 / A7 / A8 / Q7 2004 - 2010 and Audi A4 / A5 / Q5 2007 - 2015. EZS-Kessy, comfort modules, airbag modules, instrument panels and other models. Audi A6 / A 7 / A8 and VW Touareg (2010 - 2018) dashboards and information multimedia

To learn more about the component protection features and package, see the VN017 Component Protection Package information.

Other features:

• Scan/update eeprom data, Micronas MCU documentation
• Scan/update confidential information and clear crash data from Siemens and Bosch airbag modules
• Scan the component protection bits and PINs from the PCR2.1 Engine Control Module ECU on the desktop.

This package has all the functions of the listed components: AN043; AN045; AN046; AN047; AN048; AN049; AN052; AN053; AN055; AN056; AN057 and AN058

Component protection package VN017

This latest ABRITES solution offers a much wider component support of the VAG car group, especially for Audi and Volkswagen models.

VN017 allows:

• Read/update security bits of Lear Gateway components
• The possibility of changing the protection of all components, related modules, if there is access to the car being repaired and the donor
• Changing the instrument panel, via the OBD connector (no need to have access to the dismantled car or the original panel)
• Replacement of the multimedia module, via the OBD connector (no need to have access to the dismantled car or the original panel)
• Central Electronics Module (CEM) replacement, via OBD connector (no need to have access to a dismantled car or original panel)
• Replacement of temperature control BHTU, in cars A6 / A7 / A8 (4H) 2010 - 2017

Supported modules (for models with LEAR access):

• Audi A6 / A7 / A8 2010 - 2017
• Volkswagen Touareg 2010 - 2017
• Lamborghini 2010 - 2020 (4S0)

To purchase this special feature you need an active VN002 license and AVDI and an active AMS
