Launch X-861 3D wheel alignment stand

Launch X-861 3D wheel alignment stand

Launch, Germany; Warranty: 2 years

Description:

The X-861 3D Wheel Alignment Stand is a new generation device from LAUNCH. This is a highly accurate 3D measuring stand with which it is easy to start wheel alignment measurements based on easily presented data. A variety of car wheel angles can be used, including front and rear wheel tilt, front and rear wheel tilt (chamber), caster angle, center axle lift, axle perpendicularity, and more. All parameters are set with extremely high accuracy. With the X-861, the job is easy to get started, thanks to a clear sequence of operations. The Launch X-861 3D Alignment Stand for the European market uses a version of our region. The complete car comes with a complete database of cars, a printer and, of course, a computer. This is a good choice for providing professional wheel alignment services. All wheel angles of passenger cars are measured and evaluated.

Measurement parameters:

Alignment: ± 20 °

Partial alignment: ± 20 °

boiling point: ± 12 °

Caster: ± 25 °

Axial wheel displacement: ± 25 °

Flinch Angle: ± 10 °

Thrust Angle: ± 10 °

Technical data:

Input voltage: 220V AC (10A)

Input frequency: 50 ～ 60Hz

Max. power consumption: 0.5 kW

Technical characteristics:

3D measurement technology makes measurement more accurate and stable

Cameras automatically detect targets

Equipped with a high-speed camera system

Intelligent measurement with fully automatic lift and motion function

No calibration is required when in use

Informational texts describe work operations and help to understand what is being done and how

Convenient software management and easy-to-use features

English, Spanish, Russian, Polish, German, French, Italian, Portuguese, Japanese, Korean, Chinese.

Equipment:

Side beam targets

Column and height-adjustable beam

Cabinet

A set of clamps and targets

A computer

Printer

Swivel plates 2 pcs.

Brake clamp

Steering wheel lock

Four-column hydraulic lift 5.5t LAUNCH TLT-455W adapted for wheel alignment

Hydraulic four-column lift with a lifting capacity of 5.5 tons for lifting cars of various sizes in workshops and workshops. The lift is equipped with an axle lift (2 tons lifting capacity), side push plates and swivel plates for wheel alignment. Developed according to international standards and meets CE certificates.

Key features:

The distance between the rails is adjustable in three positions: 1445 - 1595 mm

Protection against overload, overload voltage and cable breakage

Safety locking along the entire lifting distance and protection against pipe rupture

Equipped with a safety valve for safe lowering in case of hose breakage and protection against pinching of the legs

Electromechanical top switch: effectively protects the car from collisions with the top

4 steel cables for force equalization

Protection of loose cables

Technical parameters:

Lifting capacity: 5500 kg

Height: 2172 mm

Width: 3445 mm

Lifting height: 1900 mm

Lowest height: 245 mm

Track length: 5600 mm

Lifting time: 70 s

Engine power: 2.2 kW

Voltage: 380 V / 50 Hz

Oil content: 12 l

Weight: 1550 kg
