Wheel alignment stand Autool XC505 3D

Wheel alignment stand Autool XC505 3D

Manufacturer: Autool

Autool XC505 3D wheel alignment stand has a stable, accurate, inexpensive and easy-to-maintain wheel alignment system, which is perfect for business development and can handle high-performance jobs. XC505 has outstanding and unique features such as user-friendly control interface, fast and comprehensive search function, excellent camera and optical device system, etc. The stand uses the most advanced technologies and has a unique expert testing mode, which can help workshop engineers to perform wheel alignment work professionally and very quickly. XC505 wheel alignment equipment, which specializes in 3D wheel alignment, is more reliable, more economical, time-saving and efficient overall. It is perfect for car manufacturers' workshops, independent workshops or tire service shops for mass retreading.

Advantages of the equipment:

• Security and stability
• Car database
• Precise setting
• Fast and efficient execution of work
• The ability to control the equipment by voice
• All in one stroller

Measurement technology using 3D cameras

The XC505 features an optical wheel positioning system and a 5-megapixel, industrial-grade HD lens for professional measurement and accurate proofreading. It not only captures target data clearly, but also accurately. This technology is suitable for various environments, the brightness can be automatically adjusted according to the ambient lighting. The recommended distance from the smart camera to the steering wheel should be 1500 - 2800 mm, and the field of view of this equipment is quite wide, which makes it possible to detect the parameters of an extremely long and extremely wide vehicle. The position of the camera is fixed and does not need to be moved, which simplifies the work of the wheel alignment bench, improves work efficiency and ensures a long service life.

Features:

• High precision targets, waterproof and with drop protection
• Fixed columns
• High precision wheel alignment technology
• Global car database
• Dual warning system, audio and visual
• Measuring system for all wheel position parameters
• Special function detection and traffic accident detection measurement system
• Extremely short calibration distance when pushing the car
• Expert mode
• Possibility to print the results of the work
• Possibility to use the equipment in different languages
• Three-year equipment warranty

Technical data:

• Supply voltage: 230 V / 50-60 Hz
• Display: 18.5" LCD
• Resolution: 1920 x 1080 px
• Lighting
• Height difference from left to right side: < 5 cm
• Measured rim sizes: 10" - 23.5"
• Ambient working temperature: 0 - 50 °C
• Working ambient humidity: < 85%

The set includes:

• 1 x column stand
• 1 x beam Components
• 1 x steering wheel locking mechanism
• 1 x brake pedal locking mechanism
• 4 x screws
• 1 x column cover
• 1 x cabinet
• 4 x locking screws
• 1 x display Mount
• 4 x targets
• 1 x PC and accessories
• 1 x coded lock
• 1 x speaker
• 2 x rotating plate
• 1 x display
• 4 x wheel clamps
